HPE PL DL360g10 4215R (3.2G/8C) 1x32G MR416i 8SFF 1x800W titan 2x10G FLR Base-T BCM57416 EIR NBD333 1U
| Powered by 2nd Generation Intel Xeon Processors | |
| Models | |
| SKU Number | P56957-421 |
| Model Name | HPE ProLiant DL360 Gen10 4215R 3.20GHz 8-core 1P 32GB-R MR416i-a NC 8SFF BC 800W PS Server |
| Chassis |
HPE DL360 Gen10 NC 8SFF BC CTO Svr (P56949-B21)
|
| Processor | 4215R (8-Core, 3.2 GHz, 130W) |
| Number of Processors | One processor with standard heatsink |
| Memory | 32 GB RDIMM 2R 2933 MT/s (1x 32 GB) |
| Network Controller | HPE Ethernet 10Gb 2-port FLR-T BCM57416 Adapter Notes: No embedded networking |
| Storage Controller | MR416i-a/4GB with Smart Storage Battery |
| Hard Drive | None included Supports only SAS/SATA Basic Carrier drives. Does not support Smart Carrier drives or NVMe drives. |
| Optical Drive | Not included (Optical Drive options available) |
| PCIe Slots | 2 PCIe: 1 x16 FH, 1 x8 LP |
| SKU Number | P56957-421 |
| Power Supply |
1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit (-B21 & -291) ------------------------------------- 1x HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit (-421) |
| Fans | 5 - Standard |
| Management | HPE iLO 5 |
| Rail Kit | SFF Easy Install w/o CMA Notes: Server does not support shelf mounted rail kits ("L" brackets). |
| Energy Star | Energy Star 3.0 |
| Form Factor | 1U Rack |
| Warranty | 3-year parts, 3-year labor, 3-year onsite support with next business day response. |
.
